Supported CPU
CPU Socket Type
AMD sTR5
CPU Type
Threadripper 7000 Series
CPU
Processor Number
Threadripper 7980X
Number of Cores / Threads
64/128
CPU Speed
3.2GHz / 5.1GHz Turbo
Cache
4MB L1 / 64MB L2 / 256MB L3
Lithography
7nm
Heatsink
High Performance Liquid Cooled Solution
Memory
Slots
4x 288 Pin
Speed
DDR5-4800
Memory Installed
256GB (4 x 64GB) ECC
Maximum Memory
1TB
Expansion Slots
PCIe 5.0 x16
3
PCIe 4.0 x16
2
Video Card
Chipset
NVIDIA
GPU
RTX 5060
Memory
8GB GDDR7
Video Ports
1x HDMI 2.1, 3x DP 1.4a
Storage Devices
SATA 6Gb/s
4
M.2 32Gb/s
3
SlimSAS
1
RAID Controller
PCIe RAID Controller
8 Channel SATA/SAS 12Gb/s
Storage Configuration
OS Drive
2TB NVMe M.2
Temp Drive
2 x 2TB NVMe M.2 (RAID0)
Cache Drive
2 x 2TB NVMe M.2 (RAID0)
Active Evidence Drive
2 x 2TB NVMe M.2 (RAID0)
Data Drive
4TB 7200RPM SATA 6Gb/s HDD
Storage RAID
4x 4TB 7200RPM SATA 6Gb/s HDD's (RAID5)
On-Board Audio
Audio Chipset
Realtek ALC1220P Surround Sound High Definition Audio CODEC
On-Board LAN
LAN Chipset
1 x Marvell® AQtion 10Gb Ethernet
LAN Chipset 2
1 x Intel® I226-LM 2.5Gb Ethernet
Wireless and Bluetooth
Wi-Fi 7
2x2 Wi-Fi 7 (802.11be)
Supports 2.4/5/6GHz frequency band
Support Wi-Fi 7 160MHz bandwidth, up to 2.8Gbps transfer rate.
Bluetooth® v5.4
Rear I/O Ports
BIOS Flashback Button
1
RJ45
2
USB 20Gbps port (Type-C®)
1
USB 10Gbps ports (Type-A)
6
USB 2.0 port (Type-A)
2
Audio Ports
2 (Line Out, Mic In)
Front I/O Ports
USB 3.0
9 (2 Top Mounted, 4 Front Mounted 3 additional system ports)
USB 3.2
5x USB 3.2 Gen2 Type-C (1 Top Mounted, 4 additional system ports)
Audio
1x Headphone, 1x Microphone
Front Mounted 5.25" Bays
Forensic Bridge
Tableau T356789iu (USB 3.0, SATA, SAS, IDE, Firewire 800, and PCIe)
Forensic Bridge/Bay
Tableau T3iu
Imaging Shelf
Hard Drive Cooling Tray w/2x Fans and 4x USB 3
Hot-Swap Bay
4x 3.5" SATA Trayless
RAID Bay
4x 3.5" SATA Trayless
Features
On-Board Power Button
Yes
On-Board Reset Button
Yes
On-Board CMOS Clear
Yes
On-Board Diagnostic LED
Yes
Operating System
Microsoft Windows 11
Professional 64-Bit
Power Supply
Maximum Wattage
1000 Watts
80 Plus Certification
80 Plus Gold Certified
Modular
Fully Modular
System Dimensions
Dimensions
Width - 9.06", Height - 24.33", Depth - 26.10"
Weight
65+ Pounds
Peripherals Included
Monitor
2x 27" LED Monitors (1920x1080)
Keyboard and Mouse
Wired or Wireless Combo
Tool Kit
Multi-Piece Toolkit to assist in Digital Evidence Gathering
USB 3.0 Card Reader
Forensic Card Reader
External USB System Hub
7 Port USB 3.2 Gen 2 Type-C Hub w/ ESD Surge Protection (3x Type-A, 4x Type-C)
