Sale!

EDAS FOX AMD Optimized + For Axiom

$14,495.00 $12,995.00

Contact Us For ICAC Pricing

*Now With Turbulent Liquid Cooling. Lower Your Core Temps by 10-12 Degrees Celsius during the most stressful processing. Avoids Core Throttling

Add to quote loading
Categories: Meet Our Family of Computers, Ryzen Threadripper Pro
  • Description
  • Tech Specs
  • Customizations

Description

  • Optimized for Axiom
  • An industry setting standard of 3 years parts and depot labor warranty.
  • AMD Threadripper Pro 5975wx 32-Core 3.6Ghz (4.5Ghz Turbo)
  • Liquid Turbulent Processor Cooling. Lowers the temperature of the Cores during heavy processing and avoid Core Throttling that occurs during Cases Processing
  • 256GB of High Speed, Error Checking DDR4 3200 Quad Channel Memory
  • An NVidia GeForce RTX 3060 with multi-monitor support to ensure a silky smooth experience whether you are processing cases, writing reports, or viewing evidence
  • A ultra-fast M.2 1TB 32Gb/s NVMe OS Drive to give you lightning fast access to your EDAS FOX System
  • 4TB M.2 NVMe for Temp
  • 3 x 4TB M.2 NVme for “Cases” (RAID0)
  • A High Capacity, High Speed 4TB 7200RPM 6Gb/s Hard Disk Data Drive to store files.
  • High Speed USB 3.1 Gen2 Type-C located on the front I/O, greatly improving the speed of the onboard USB 2.0 ports.
  • 6 x Hot Plug SATA Tray-less Bays, giving you access to easy to use, high speed hard drive bays for extra storage.
  • Write-Blocked Multi-Card Reader to ensure forensically sound access to all types of media cards.
  • An integrated Write-Blocked Forensic Bridge, With USB 3.0, SATA, IDE, SAS, FireWire, and PCIe Connections. Tableau T356789iu or Logicube Write Protect Bay.
  • A highly efficient 1000 Watt 80 Plus Gold Certified Fully Modular Power Supply to ensure stability, and high power capacity for all your needs.
  • 2 x 24 Inch LED Monitors
  • Wireless Keyboard / Mouse Combo (Wired available at no charge for DOD or other such requirements)
  • Call for pricing on requested upgrades from specifications

Supported CPU

CPU Socket Type
AMD Socket sWRX8
CPU Type
Threadripper Pro

CPU

Processor Number
Threadripper Pro 5975wx
Number of Cores / Threads
32 / 64
CPU Speed
3.6GHz / 4.5GHz Turbo
Cache
128MB
Lithography
7nm
Heatsink
Premium Grade Quiet Air Cooling Solutions
Heatsink-Option
Liquid Turbulent Processor Cooling

Chipset

Chipset
AMD sWRX8

Memory

Slots
12x DIMM
Speed
DDR4-3200
Memory Installed
256GB (8 x 32GB) ECC
Maximum Memory
768GB
Channel Supported
Quad Channel

Expansion Slots

PCIe 3.0 x16
7

Video Card

Chipset
NVIDIA
GPU
RTX 3060
Memory
12GB GDDR6
Video Ports
1x HDMI / 3x DP

Storage Devices

SATA 6Gb/s
8
M.2 32Gb/s
3

Storage Configuration

OS Drive
1TB M.2 NVMe 32Gb/s
Temporary Files
4TB M.2 NVMe 32Gb/s
Cases
3x 4TB M.2 NVMe 32Gb/s (RAID0)
Data Drive
4TB 7200RPM SATA 6Gb/s HDD

On-Board Audio

Audio Chipset
Relatek ALC4080 7.1 Surround Sound High Definition Audio CODEC

On-Board LAN

LAN Chipset
2x Intel X550-AT2 10Gb Ethernet
Max LAN Speed
10Gbps

Rear I/O Ports

BIOS Flashback
1
RJ45
2
USB 3.2 Gen 2
9 (8x Type-A, 1x Type-C)
USB 3.2 Gen 2x2
1x Type-C
Audio Ports
7.1 Channel Audio I/O

Front I/O Ports

USB 3.0
12 (2 Top Mounted, 10 Front Mounted)
USB 3.1
2x USB 3.1 Gen2 Type-C (1 Top Mounted, 1 Front Mounted)
eSATA
1x 6Gb/s eSATA
Audio
1x Headphone, 1x Microphone

Front Mounted 5.25" Bays

Optical Disk Drive
16x Blu-Ray Burner
Forensic Bridge
Tableau T356789iu or Logicube Write Protect Bay (USB 3.0, SATA, SAS, IDE, Firewire 800, and PCIe)
Cooling Bay
2.5"/3.5" Hard Drive Cooling Bay For Imaging
SSD Drive Bay
4x 2.5" SATA Trayless
Data Drive Bay
1x 3.5" SATA Trayless
USB 3.0 Hub
8 Ports
USB 3.1 Hub
1x Gen2 Type-C, 2x Gen1 Type-A
Hot-Swap Bay
6x 3.5" SATA Trayless

Features

On-Board Power Button
Yes
On-Board Reset Button
Yes
On-Board CMOS Clear
Yes
On-Board Diagnostic LED
Yes

Operating System

Microsoft Windows 10
Professional 64-Bit

Power Supply

Maximum Wattage
1000 Watts
80 Plus Certification
80 Plus Gold Certified
Modular
Fully Modular

System Dimesions

Dimensions
Width - 9.06", Height - 24.33", Depth - 26.10"
Weight
65+ Pounds

Peripherals Included

Monitor
2x 24" LED Monitors (1920x1080)
Keyboard and Mouse
Wired or Wireless Combo
Tool Kit
Multi-Piece Toolkit to assist in Digital Evidence Gathering
USB 3.0 Card Reader
Forensic Card Reader
