Supported CPU
CPU Socket Type
LGA1700
CPU Type
Core i7
CPU
Processor Number
i7-12700K
Number of Cores/Threads
12 / 20 (8P+4E)
CPU Speed
3.6GHz / 5.0GHz Turbo
Cache
25MB
Lithography
7nm
Heatsink
Liquid Cooled Solution
Chipset
Chipset
Z690
Memory
Slots
2x DIMM
Speed
DDR5-4800
Memory Installed
32GB (2x 16GB)
Maximum Memory
64GB
Channel Supported
Dual Channel
Expansion Slots
PCIe 3.0 x16
1
Storage Devices
SATA 6Gb/s
4
M.2 32Gb/s
2
Storage Configuration
OS Drive
512GB SATA 6Gb/s SSD
Evidence Drive
1TB SATA 32Gb/s NVMe M.2
Data Drive
4TB 7200RPM SATA 6Gb/s HDD
On-board Audio
Audio Chipset
ROG SupremeFX High Definition Audio CODEC S1220A
On-board LAN
LAN Chipset
Intel 2.5Gb (Wi-Fi 6E 802.11a/b/g/n/ac/ax + Bluetooth 5.2)
Max LAN Speed
10/100/1000/2500Mbps
Rear I/O Ports
USB 2.0
2
USB 3.2 Gen1
2
USB 3.2 Gen2
2
Thunderbolt 4
2x Type-C
RJ45
1
Video Out
1x HDMI
S/PDIF Out
1x Optical
Audio Ports
8 Channel
Front I/O Ports
USB 2.0
2
USB 3.0
7
Front Mounted 5.25" Bays
Forensic Bridge
Tableau T356789iu (Firewire800/SATA/SAS/IDE/USB 3.0/PCI)
USB 3.0 Hub
7 Ports
Blu-Ray / Hot Swap Combo Bay
Blu-Ray Drive with 3.5" Hotswap Bay
Operating System
Microsoft Windows 10
Professional 64-Bit
Power Supply
Maximum Wattage
500 Watts
80 Plus Certification
80 Plus Gold Cerified
Software Pre-Installed
Data Analysis Reporting Tool
HTCI DART (2 Week Demo)
HTCI SIM Utility
Reads and Duplicates SIM Cards
System Dimensions
Dimensions
Width - 8.69", Height - 8.90", Depth - 12.76"
Weight
20+ Pounds
Peripherals Included
Keyboard and Mouse
Wired or Wireless Combo
Tool Kit
Multi-Piece Toolkit to assist in Digital Evidence Gathering
